9
SYSTEM MENU
MODE SET UP UP/DOWN DESCRIPTION
DMX Mode
Address d001 ~ d512 Set DMX starting address
Channels
Ch06
Select DMX channel mode
Ch07
Ch08
Ch11
Ch12
No DMX Mode
blAc
When DMX signal is lost or interrupted,
unit switches all LEDs off
LASt
When DMX signal is lost or interrupted,
unit holds last state before signal was
lost
ProG
When DMX signal is lost or interrupted,
unit will run internal program
nAnU
When DMX signal is lost or interrupted,
the unit will default to manual setting
Delay Mode dr-0 ~ dr-4 Select delay mode
SEcd Mode SEcd Mode SEcd Set unit to secondary mode
Dimmer Mode
Red dimmer r000 ~ r255 Adjust red color intensity
Green dimmer G000 ~ G255 Adjust green color intensity
Blue dimmer b000 ~ b255 Adjust blue color intensity
White dimmer U000 ~ U255 Adjust white color intensity
Amber dimmer A000 ~ A255 Adjust amber color intensity
UV dimmer u000 ~ u255 Adjust UV intensity
Flash FS00 ~ FS15
Adjust ash speed; 00 is off, 01 is slow-
est, 15 is fastest
Sound Mode
Mode select So01 ~ So16 Select from 16 built in sound modes
Sensitivity select SJ-1 ~ SJ-8
Adjust sound sensitivity; 1 is lowest level
and 8 is highest level
Auto Run
Mode
Color Fade Mode AF01 ~ AF16 Select from 16 color fade modes
Color Change Mode AJ01 ~ AJ16 Select from 16 color change modes
Color Fade & Color
Change
A-JF
Color fade and color changes modes run
in a continuous cycle
Speed Set SP01 ~ SP16 Adjust speed of cycle
Static Color
Select Mode
Color Select CL00 ~ CL63 Select from the built-in static colors
Flash FS00 ~ FS15
Adjust ash speed; FS00 is off, FS01 is
slowest, FS15 is fastest
CONTINUED ON NEXT PAGE
