Dimmer Curve Setting:
1. Plug the fixture in and press the MODE button until “d.XXX” is displayed. Now press the SET UP
button until “dr-X” is displayed, “X” representing a number between 0-4.
2. There are 5 dimmer curve settings to choose from. Please see the Dimmer Curve Diagram Chart
on page 26 to see the settings and their respective beginning and ending fade times.
Default Running Mode:
This is a default running mode. When this mode is activated all modes will return to their default set-
tings.
1. Plug the fixture in and press the MODE button until “dXX” is displayed. “XX” represents either
“on” or “oFF”.
2. Press the SET UP button until “dEFA” is displayed.
3. Press the UP and DOWN buttons simultaneously. Press the MODE button to exit.
Mega HEX Par Operating Instructions
Mega HEX Par Master-Slave Configuration
Master-Slave Configuration:
This function will allows you to link units together to run in a Master-Slave set-up. In a Master-Slave
set up one unit will act as the controlling unit and the others will react to the controlling units built-in
programs. Any unit can act as a Master or as a Slave however, only one unit can be programmed to
act as the “Master.”
Master-Slave Connections and Settings:
1. Daisy chain your units via the XLR connector on the rear of the unit. Use standard XLR data
cables to link your units together. Remember that the Male XLR connector is the input and the
Female XLR connector is the ouput. The first unit in the chain (master) will use the female XLR
connector only. The last unit in the chain will use the male XLR connector only.
2. Connect the rst “Slave” unit to the “Master.”
3. Set the “Master” unit to your desired mode of operation. On the “Slave” unit’s press the MODE
button until “SLAv” is displayed. The “Slave” unit(s) will now follow the “Master”.
ADJ Products, LLC - www.adj.com - Mega HEX Par User Manual Page 12
