2. TOPOLOGY
Figure 2-1 FiRe-78-4 DAS topology
3. CABLE CONNECTION
3.1 AC Power
Figure 3-1 AC Power port
AC power is accepted through a standard 3-wire male plug (MS3106A-22-2S) with phase, neutral and ground leads.
The AC power is wired to a high efficiency DC switching power supply which is UL listed. The power supply runs the
amplifiers and device including RF Module, controller, LED, etc.
The metal enclosure of this equipment is connected to ground.
