3000EN Series: Installation Instructions
5-4
Entd A022-4063 1
Rcvd A022-4064 1
If Serial or Loop
Numbers do not match
after activating the
transmitter
[∗] to continue
If the serial number transmitted does not match the serial
number entered, a display similar to the one shown appears.
If the loop number does not match, it will also be displayed.
If so, activate the loop input or button on the transmitter once
again. If a match is not obtained (i.e., summary display does
not appear), press the [#] key twice and then enter (or
transmit) the correct serial number.
10 INPUT S/N: L
A000-0000 0
To Delete a Serial No.
enter 0 in loop number field
# = undo deletion
[∗] to continue
To delete an existing serial number, enter 0 in the loop
number field. The serial number will change to 0's.
If 0 was entered in error, simply re-enter the loop number or
press [#], and the serial number will return to the display.
Zn ZT RC In: L
10 03 10 RF: 1s
Summary Screen
[∗] to continue
If the serial number transmitted matches the serial
number entered, the touchpad will beep 3 times and a
summary display will appear, showing that zone's
programming. Note that an “s” indicates that a
transmitter’s serial number has been enrolled.
Press [✱] to accept the zone information and continue.
PROGRAM ALPHA?
0 = NO 1 = YES 0
Alpha Descriptors
0 = no
1 = yes
[∗] to continue
If you want to program descriptors for zones now, enter 1
(Yes) and refer to the Alpha Descriptor Programming
section for available descriptors.
ENTER ZN NUM.
(00 = QUIT) 11
Next Zone Number
00 = quit
[∗] to continue
If 0 (No) was entered above, the system will return you to the
ENTER ZN NUM. prompt for the next zone.
When all zones have been programmed, enter 00 to quit.
