ADT Safewatch Pro 3000EN Installation And Setup Guide

3000EN Series: Installation and Setup Guide
1-2
Compatible Devices
• Supports up to 8 Addressable Touchpads: English Display Touchpad (6150ADT), Custom English
Display Touchpad (6160ADT), and Custom English Display Voice Touchpad (6160VADT)
• Supports up to four iCenter (AUI) or 6270ADT touch screen devices in addition to up to 8
touchpads (described above).
• Supports up to five (5) 4219, 4229 addressable zone expander modules for up to 40 expansion zones
• Up to 16 output relays and/or Powerline Carrier Devices (X-10 type) plus two on-board triggers
-- Use any combination of 4204, 4229 and or Powerline Carrier Devices.
-- Up to 48 output functions
• Ademco 4286 Phone Module (Part. 1 only); provides access to the system via on premises or off-
premises phones for arming, disarming, etc., plus control of relay outputs and Powerline Carrier
devices.
• Audio Alarm Verification (using AAV module, such as ADEMCO UVS); can be used in conjunction
with an output trigger to permit voice dialog between an operator at the central station and a
person at the premises. Alternatively, the AVS-ADT system can be used to provide AAV via phone
line or AlarmNet IP/GSM (using a GSMV-ADT module).
• Alarm output provides a 12VDC, 2 AMP output that can drive the compatible sounders; steady
output for burglary/panic, or temporal pulse output (3 pulses – pause – 3 pulses – pause – 3 pulses.
. .) for fire. Uses current limiting circuitry for protection.
• Auxiliary Power Output: 12VDC, 600 mA maximum (uses circuit protection).
• Backup Battery: Rechargeable (sealed lead-acid type) 12VDC, 4AH minimum.
• Long Range Radio (Communication Device): Primary telephone number messages can be reported
via ECP connection to various communication devices (check compatibility and availability of
specific models)
• AC Power Supply: Plug-in 120VAC transformer, ADEMCO 1321 (1321CN in Canada) or, if using
Powerline Carrier devices, ADEMCO 1361X10 Transformer Module
NOTE: All devices and accessories used in a Canadian installation must be Listed for use in Canada.
Important Installation Highlights (Installer Please Read)
• This system uses addressable touchpads and Zone Expander Modules (see table of addresses in
Programming Overview section).
• Touchpads must be set for addresses 16-23 (first touchpad is address 16, which is different from
previous controls) and programmed in data fields *190-*196.
• Zone Expander Modules must be set for specific addresses (07-11), based on the zone numbers used
(see table of addresses in 4219/4229 Expansion Zones section).
• 4204 Relay Modules must be set for specific addresses (12-15; see Connecting Relay Modules
section).
• This control will not power-up unless AC power is connected (will not power-up on battery alone).
However, once the system is powered up, it will operate on battery power in the event of AC loss.
• Relays have two programming menu modes: Use *79 Menu mode to map module addresses and
device (output) numbers. Use *80 Menu mode to define the output functions (see Output Device
Programming section).
• This system supports programmable function keys. Use *57 Menu mode to define the function keys
(see Function Key Programming section).
• This system provides various paging features. Refer to the Programming Overview section for a
summary on pager programming.

ADT Safewatch Pro 3000EN Specifications

General

Brand	ADT
Model	Safewatch Pro 3000EN
Category	Security System
Language	English
