Back Panel
Connector Description
Power 1 & 2 Redundant AC Power, Standard 3 pin computer power plug
(Auto range 70-240 VAC Input)
GigE UDP or RTP multicast transport ingress port (SMPTE 2022)
COM2 API Serial Communication Interface **
COM1 Serial Port Used for Troubleshooting (Terminal)
Ethernet 10/100 base T ethernet interface (Monitoring/Management)
DVC Parport 9-pin parallel I/O interface for control systems **
RS422 Not Currently Supported **
GPIO Tally and Control Port
Decoder
Analog Audio Out Balanced analog audio out. Stereo pairs 1 & 2 ( 600 Ohm Balanced )
