AES Audio Out 1-4 x4 75 Ohm AES-3 BNC
ASI/SDI In 75 Ohm terminated BNC input. SDI input features are not active at
this time.
x3 ASI OUT x3 75 Ohm BNC ASI output per EN5000839
Sync In Standard analog video sync separation for NTSC, PAL, 480I/P,
576I/P, 720P, and 1080I/P/PsF from Composite Video (CVBS). Bi-
level & tri-level sync compatible. BNC
CVBS Out 75 Ohm BNC Standard Definition Composite Video Output
HDMI Out* SD video over HDMI is not supported.**VERSION 06 AND NEWER
HARDWARE DOES NOT SUPPORT HDMI OUTPUT**
SDI Out Banks x2 Pair of 75 Ohm Outputs from decoder: Video/Audio/VBI (SMPTE
259M-C - SD & SMPTE 292M - HD) BNC
Demodulator (
Optional )
RF 1 & 2 x2 RF Input, 75 Ohm F-Connector
DB9-M Analog audio output pinout
PIN Designation Function
1 NC No Connect
2 GND
Ground
3 L+ Left +
4 R+ Right +
5 GND Ground
6 NC No Connect
7 GND Ground
8 L- Left -
9 R- Right -
