Adtec RD-71 - Front Panel LED Indicators

Front Panel LED Indicators
Transport
Indicator
Function
Decode
Off - Decoder is idle.
On - Decoder is active.
ASI / IP /RF
Off - No services detected on the input.
On - Services detected on the input.
Lock 1 / Lock 2
Off - Tuner is not locked
On - Tuner is locked
IP Out
Off - IP Egress is idle.
On - IP Egress is active.
Bars
Off - All B/T/ID options are disabled.
On - B/T/ID options are enabled.
Audio Decode
Indicator
Function
A1 through A8
Off - Audio engine is not active.
On - Audio engine is actively decoding or performing passthru.
Blinking - Audio engine is in a failure mode (no passthru or audio
decoding)
System
Indicator
Function
Alarm
Off - No system alarms.
On - System alarm.
(NTP or FAN alarm)
BISS
Off - Decryption configuration is turned OFF
On - Decryption configuration is set to BISS1 or BISSE
Link
Off - Network communication link not detected
On - Network communication link detected
Busy
Off - No network activity
On - Network traffic present
13
