Adtec RD-71 - VBI Menu

VBI Menu
Item
Function
Options
SMPTE 2038
Pass-through
Configures the SDI ANC passthrough feature.
OFF
ON
AFD
SDI Line
Number
Configures the SDI ANC line output of AFD (
SDI Output Port 1 and 2 )
0 - Disabled
7 - 22
SDI Alt. Line
Number
Configures the SDI Alternate ANC line output of
AFD ( SDI Output Port 3 and 4 )
0 - Disabled
7 - 22
Closed Captions
CVBS Line
Number
Enables/Disables the CVBS/SD-SDI port line
number for waveform closed captions.
0 - Disabled
21 - Output captions
if present
SDI Line
Number
Configures the SDI ANC line output of
EIA-608/708 Closed Captions ( SDI Output Port
1 and 2 )
0 - Disabled
7 - 22
SDI Alt. Line
Number
Configures the SDI Alternate ANC line output of
EIA-608/708 Closed Captions ( SDI Output Port
3 and 4 )
0 - Disabled
7 - 22
Teletext
CVBS Line
Number
Enables/Disables the CVBS/SD-SDI port line
number for waveform Teletext.
0 - Disabled
22 - Output teletext
if present
SDI Line
Number
Configures the SDI ANC line output of
OP47/Teletext ( SDI Output Port 1 and 2 )
0 - Disabled
7 - 22
SDI Alt. Line
Number
Configures the SDI Alternate ANC line output of
OP47/Teletext ( SDI Output Port 1 and 2 )
0 - Disabled
7 - 22
