DVC Parport
9-pin parallel I/O interface for control systems
RS422
Not Currently Supported
Decoder
Analog Audio Out
Balanced analog audio out. Stereo pairs 1 & 2 ( 600 Ohm Balanced )
AES Audio Out 1-8
x8 75 Ohm AES-3 BNC
ASI/SDI In
75 Ohm terminated BNC input. SDI input features are not active at
this time.
x3 ASI OUT
x3 75 Ohm BNC ASI output per EN5000839
Sync In
Standard analog video sync separation for NTSC, PAL, 480I/P,
576I/P, 720P, and 1080I/P/PsF from Composite Video (CVBS).
Bi-level & tri-level sync compatible. BNC
CVBS Out
75 Ohm BNC Standard Definition Composite Video Output
Digital Video
Digital Video Output.
SDI Out Banks
x4 Outputs from decoder: Video/Audio/VBI (SMPTE 259M-C - SD,
SMPTE 292M - HD, SMPTE 424M - 3G).
SDI Bank A = x2 SD/HD/3G-SDI BNC Outputs
SDIALT Bank B = x1 SFP (for Optical SFP module) SD/HD/3G-SDI
Output and x1 SD/HD/3G-SDI BNC.
note*: 3G-SDI Outputs have selectable Level A and Level B Dual
Link output control to retain interoperability with other third party
3G devices. The default mapping level is Level A.
Demodulator
(Optional)
RF 1 - 4
x2 or x4 RF Inputs (Demod option specific), 75 Ohm F-Connector
DB9-M Analog audio output pinout
PIN
Designation
Function
1
NC
No Connect
2
GND
Ground
3
L+
Left +
4
R+
Right +
5
GND
Ground
