LED STATUS
The LEDs are located beneath the plastic housing and are only
visible after power has been applied. The following table provides
the LED status during normal operations.
Label Status Indication
POWER
Off
Green
AC or battery off
No Failure
FIBER
2
Off
Green
Green Flashing
Fast
No connection to the OLT,
open fiber, failure at the ONT,
or power is Off
DS signal present and is within
operating range
Ranging in Progress
INTERNET
Off
Green
No IP address configured on
WAN Interface, or Power is
Off
WAN Interface is configured
with IP address
GE 1-4
2
Off
Green
Green Flashing
Fast
Link is down or not equipped
Link is up
Data is being sent or received
USB
2
Off
Green
Green Flashing
Fast
Power Off or no device con-
nected
Device connected
Data is being sent or received
2.4GHZ
2
Off
Green
Green Flashing
Fast
Power is Off, or Wireless
2.4GHz is Disabled
Wireless 2.4GHz is Enabled
Data is being sent or received
on 2.4GHz
5GHZ
2
Off
Green
Green Flashing
Fast
Power is Off, or Wireless 5GHz
is Disabled
Wireless 5GHz is Enabled
Data is being sent or received
on 5GHz
PHONE 1-2
2
Off
Green
Green Flashing
Slow
Unequipped or on-hook and
not ringing
Line is off-hook
Line in ringing state
WPS
2
Off
Green
Green Flashing
Fast
Power Off or WPS is Disabled
WPS is Enabled
WPS push button pressed and
device is ready to accept con-
nection
REGISTRATION ID
Registration ID is performed by Serial Number Activation. This
occurs when the 424RG ONT is “Discovered” by the OLT.
If AOE Auto Upgrade is active, a new 424RG ONT installation will
be detected and a fast blinking FIBER LED will indicate a new
software download has commenced. This may take 5 - 10 minutes
to complete.
SPECIFICATIONS
Refer to the following for a list of all specifications for the 424RG
ONT.
■ Electrical
♦ Voltage: 12.0 Volts typical
♦ Minimum Voltage: 10.0 Volts
♦ Maximum Voltage: 13.9 Volts
♦ Power Consumption: Typical 22.0 watts
■ Optical
♦ TX min power: +0.5 dBm
♦ TX max power: +5.0 dBm
♦ RSSI max sensitivity: –27.0 dBm
♦ R.0X overload: –8.0 dBm
♦ TX wavelength: 1310 nm typical
♦ RX wavelength: 1490 nm typical
■ Physical
♦ Height: 10.8 inches (27.5 centimeters)
♦ Width: 1.8 inches (4.57 centimeters)
♦ Depth: 7.6 inches (19.3 centimeters)
♦ Weight: 1 pounds (0.45 kilograms)
■ Environmental
♦ Operational Temperature: 23°F to +113°F (0°C to +45°C)
♦ Storage Temperature: –40°F to 185°F (–40°C to +85°C)
♦ Relative Humidity: 90%, noncondensing
MAINTENANCE
The 424RG ONT does not require routine hardware maintenance
for normal operation. ADTRAN does not recommend that repairs
be attempted in the field. Repair services may be obtained by
returning the defective unit to ADTRAN. Refer to the warranty for
further information. Field support for software is provided through
upgrade facilities.
SAFETY AND REGULATORY
Refer to the Safety and Regulatory Notice for this product (P/N
61287781F1-17) for detailed safety and regulatory information.
