2 Copyright © 2008 ADTRAN, Inc. All Rights Reserved. Quick Start Guide, 61203870G1-13B, March 2008 3
CONFIGURE THE UNIT’S IP ADDRESS
The following steps create an IP address and subnet mask for Ethernet port 0/1. If you are not
sure what IP address to assign, please contact your network administrator.
1. At the # prompt, enter config terminal.
2. At the (config)# prompt, enter interface eth 0/1 to access the configuration parameters for
the Ethernet port located on the rear of the unit.
3. Enter ip address 10.26.12.12
255.255.255.0 to assign an IP address to the Ethernet port
using a 24-bit subnet mask.
4. Enter ip route 0.0.0.0
0.0.0.0 192.22.72.2 to add a default route to the route table. If
necessary, contact your network administrator to obtain the IP address (and subnet mask)
for your particular configuration.
5. Enter no shutdown to activate the interface to pass data.
6. Enter exit to exit the Ethernet interface commands and return to the Global Configuration
mode.
ENABLE TELNET ACCESS
The following steps create a password of adtran for Telnet access. By default, Telnet access is
enabled with a password of password.
1. Verify that the prompt of your unit displays (config)#.
2. Enter line telnet 0 4 to change the configuration parameters for the Telnet sessions.
3. Enter login to initiate Telnet access.
4. Enter password adtran
to change the login password for the Telnet sessions.
5. Enter exit to return to the Global Configuration mode.
6. Verify that the prompt of your unit displays (config)#.
7. Enter do write memory to save the current configuration.
The configuration parameters used in the examples outlined in this
document are for instructional purposes only. Please replace all
underlined entries (
example) with your specific parameters to configure
your application.
Depending on your configuration, you may need to set a default gateway
as well using the (config)#ip default gateway command. If IP routing is
enabled on the unit, do NOT set a default gateway.
CONFIGURE YOUR APPLICATION
More detailed documentation for configuring your ADTRAN unit is provided on the AOS
Documentation CD included in your shipment. For more detail on hardware setup, refer to the
appropriate NIM quick start guides and the hardware installation guide. For more detail on
configuring your system, refer to the AOS Command Reference Guide, configuration guides, and
technical support notes.
Important: For additional details on product features, specifications,
installation, and safety, refer to the appropriate hardware installation
guide on the AOS Documentation CD shipped with the base unit and
available online at www.adtran.com.
CONSOLE PINOUTS
Pin Name Description
1 DCD Data Carrier Detect (output)
2 RD Receive Data (output)
3 TD Transmit Data (input)
4 DTR Data Terminal Ready (input)
5 SG Signal Ground
6 DSR Data Set Ready (output)
7 — Unused
8 CTS Clear to Send (output)
9 — Unused
ETHERNET PINOUTS
Pin Name Description
1 TX1 Transmit Positive
2 TX2 Transmit Negative
3 RX1 Receive Positive
4, 5 — Unused
6 RX2 Receive Negative
7, 8 — Unused
