SPECIFICATION
Model AMM213TD AMM240WTD
LCD Panel 21.3 TFT LCD Panel 24.0 TFT LCD Panel
Type Active Matrix Active Martrix
Resolution 1600 x 1200 @ 60Hz 1920 x 1200 @ 60Hz
Pixel Pitch 0.27mm 0.27mm
Display Color 16.7M colors 16.7M colors
Color Tone Up to 256 color tone Up to 256 color tone
Response Time <25ms Typ. <25ms Typ.
Face Finishing
Protective Filter with Anti-Reected Hard
Coated
Protective Filter with Anti-Reected Hard
Coated
Viewing Angle +/- 85°(Horizontal), +/- 85° (vertical) +/- 85°(Horizontal), +/- 85° (vertical)
Input Signal (Analog & Digital)
Sync (Analog) 2.5~5.0Vp-p separated sync 2.5~5.0Vp-p separated sync
Composite Sync (Analog) Composite Video (NTSC/PAL) Composite Video (NTSC/PAL)
Y/C Sync (Analog) S-Video (NTSC/PAL) S-Video (NTSC/PAL)
Input Impedance (Analog)
Video - 75 Ohm
Sync - 1k Ohm
Video - 75 Ohm
Sync - 1k Ohm
Digital 24-bit MSB RGB TMDS Dual Link 24-bit MSB RGB TMDS Dual Link
Scanning Frequency
Horizontal 31.47~79.98kHz 31.47~79.98kHz
Vertical 50~85Hz 50~75Hz
Display Size
H x V 17 x 12.8 (432mm x 324mm) 20.4 x 12.8 (518.4mm x 324mm)
Brightness, Contrast Radtio, Gray Scales
Brightness 750 cd/m2 (Typ.) 400 cd/m2 (Typ.)
Contrast Ratio 1100:1 (Typ.) 1000:1 (Typ.)
Signal Input Connector
Video
DVI, HD15, SD/HD-SDI 1 and 2 , Compo-
nent Y/G, Pb/B, Pr/R, H/CS, VS, C-Video
and S-Video
DVI, HD15, SD/HD-SDI 1 and 2 , Compo-
nent Y/G, Pb/B, Pr/R, H/CS, VS, C-Video
and S-Video
Communication DB9 (RS232) DB9 (RS232)
Signal Output Connector (Loop Through)
Video
SD/HD-SDI, Component Y/G, Pb/B, Pr/R,
H/CS, VS, C-Video and S-Video
SD/HD-SDI, Component Y/G, Pb/B, Pr/R,
H/CS, VS, C-Video and S-Video
Operating/Storage Environment
Operating Temperature 32° ~ 104°F (0° - 40°C) 32° ~ 104°F (0° - 40°C)
Storage Temperature -4° ~ 140°F (-20° - 60°C) -4° ~ 140°F (-20° - 60°C)
Storage Humidity 10 ~ 85%RH (without condensation) 10 ~ 85%RH (without condensation)
VESA Mounting
100mm x 100mm 100mm x 100mm
Power Source
Display Monitor DC 24V DC 24V
AC-Adapter AC100~240V 50-60Hz, 3.0A AC100~240V 50-60Hz, 3.0A
Regulations
Safety, EMI & Environ-
mental
UL 60601-1, EN60601-1, EN60601-1-2,
FCC, CE, CCC, VCCI, ROHS, IP:X1 Compli-
ance
UL 60601-1, EN60601-1, EN60601-1-2,
FCC, CE, CCC, VCCI, ROHS, IP:X1 Compli-
ance
Dimension
Free Mount
20 (W) x 15.31 (H) x 3.76 (D)
512mm(W) x 389mm(H) x 95.5mm(D)
23.54 (W) x 15.07 (H) x 4.39 (D)
598mm(W) x 382.9mm(H) x 111.5mm(D)
Weight
Free Mount 14.65 lbs (6.66Kg) 16.45 lbs (7.47Kg)
Optional Module
Base Stand Adjustable high, swivel and tilt base stand Adjustable high, swivel and tilt base stand
