Connectors
DC Input
Connector Jack Power Input
Video Input
24 pin DVI-I connector.
DDWG or equivalent connector.
Pin Description Pin Description Pin Description
1 T.M.D.S. Data2- 11 T.M.D.S. Data1 Shield 21 NC
2 T.M.D.S. Data2+ 12 NC 22 T.M.D.S. Clock Shield
3 T.M.D.S. Data2 Shield 13 NC 23 T.M.D.S. Clock+
4 NC 14 +5V Power 24 T.M.D.S. Clock-
5 NC 15 Ground (for +5V) 25 Analog Red
6 DDC Clock 16 Hot Plug Detect 26 Analog Green
7 DDC Data 17 T.M.D.S. Data0- 27 Analog Blue
8 Analog V - Sync 18 T.M.D.S. Data0+ 28 Analog H - Sync
9 T.M.D.S. Data1- 19 T.M.D.S. Data0 Shield 29 GND(for analog signal)
10 T.M.D.S. Data1+ 20 NC
15 pin VGA connector.
Pin Description Pin Description Pin Description
1 GRED 6 GND 11 NC
2 GGREEN 7 GND 12 GSDA
3 GBLUE 8 GND 13 IHS
4 GND 9 G5V 14 IVS
5 GND 10 GND 15 GSCL
S - Video connector.
C - Video connector.
Pin Description Pin Description
1 GND 3 CHROMA
2 GND 4 LUMA
Pin Description
1 DATA IN / OUT
Pin Description Pin Description
1 GND 4 NC
2 GND 5 VCC_24V
3 VCC_24V
AMM213TD/AMM240WTD 33
ENGLISH
