Advance acoustic Adfinity X20R ecoflex User Manual (English)

Questions and Answers:

J
Janet MyersAug 6, 2025
What to do if Advance acoustic Floor Machine has insufficient recovery water vacuuming?
- T
  Thomas ReidAug 6, 2025
  If you're experiencing insufficient recovery water vacuuming with your Advance acoustic Floor Machine, several factors could be at play. First, check if the recovery water tank is full and empty it if necessary. Next, ensure the hose is properly connected to the squeegee. Also, inspect the vacuum grid for clogs or a stuck float and clean or check it accordingly. Examine the squeegee for dirt or worn/damaged blades, cleaning or replacing them as needed. Lastly, verify that the tank cover is correctly closed, the gasket is intact, and the compensation hole is clear. Close the cover correctly, replace the gasket or clean the compensation hole.
I
Ivan MaldonadoAug 11, 2025
Why the brushes do not work and the red warning led is on in Advance acoustic Adfinity X20R ecoflex Floor Machine?
- K
  Kenneth HowardAug 12, 2025
  If the brushes on your Advance acoustic Floor Machine aren't working and the red warning light is on, it's likely that the batteries are discharged. To resolve this, charge the batteries.
A
Andrew PachecoAug 17, 2025
How to troubleshoot if motors do not work and no warning led turns on in Advance acoustic Floor Machine?
- S
  Stephen RivasAug 17, 2025
  If the motors aren't working and no warning lights turn on for your Advance acoustic Floor Machine, it could be due to a disconnected battery connector. Ensure it is properly connected. Alternatively, the batteries might be completely discharged, so charge them fully.
A
Alicia WilliamsAug 21, 2025
What to do if Advance acoustic Floor Machine has insufficient solution flow to the brushes?
- A
  Alan HarveyAug 21, 2025
  If you're experiencing insufficient solution flow to the brushes on your Advance acoustic Floor Machine, the solution/clean water filter might be dirty, so clean it. Another possibility is that the tank is dirty, potentially clogging the drain hole; clean the tank. Finally, if your machine has an EcoFlex™ system, the tank might be dirty or encrusted; in this case, drain it.
M
Mary HarperAug 26, 2025
How to fix marks caused by the squeegee in Advance acoustic Adfinity X20R ecoflex?
- T
  Tamara LucasAug 27, 2025
  If your Advance acoustic Floor Machine is leaving marks caused by the squeegee, there might be debris under the squeegee blades, so remove any debris. The squeegee blades could also be worn, chipped, or torn, requiring replacement. Another possibility is that the squeegee hasn't been balanced with the handwheel, so balance it.
M
Michelle OneillAug 31, 2025
Why the warning leds flash simultaneously in Advance acoustic Floor Machine?
- J
  James VillarrealSep 1, 2025
  If the warning LEDs are flashing simultaneously on your Advance acoustic Floor Machine, the brush deck motor is likely overloaded. Try using a less aggressive brush that is more suitable for the floor you are cleaning.

Advance acoustic Adfinity X20R ecoflex Specifications

General

Brush Speed	200 RPM
Cleaning Path	20 in
Solution Tank	16 gal
Recovery Tank	18 gal
Power Cable	75 ft
Power	1500 W
Speed	200 RPM
Voltage	120 V
Frequency	60 Hz
Brush Diameter	20 in

Summary

Introduction and General Information

Manual Purpose and Contents

Explains the manual's scope, technical data, safety, operation, storage, maintenance, spare parts, and disposal.

Target Audience

Specifies the manual is for operators and technicians qualified for machine maintenance.

Manual Storage Guidelines

Instructions for storing the manual near the machine in an adequate case, away from liquids.

Machine Identification Data

Details on locating machine model and serial number on the plate for spare parts ordering.

Operation Capabilities

Describes scrubber-dryer use for smooth, solid floors in indoor environments.

Unpacking and Delivery Procedures

Procedures for unpacking, checking for damage, and verifying contents upon delivery.

Safety Precautions

Warning Symbols Explained

Explains warning symbols (DANGER, WARNING, CAUTION, NOTE, CONSULTATION) used in the manual.

General Safety Instructions

Provides specific warnings and cautions regarding potential damages to people and the machine.

Machine Description

Machine Structure Overview

Lists and describes the various components of the machine's structure.

Control Panel and Battery Charger

Control Panel Functions and Indicators

Details the switches, LEDs, and indicators on the machine's control panel.

Battery Charger Data Inspection Window

Explains the components and indicators of the battery charger data inspection window.

Specifications and Options

Optional Accessories and Features

Lists optional accessories and components available for the machine.

Technical Data Specifications

Provides detailed specifications and performance data for different machine models.

Wiring Diagrams

Wiring Diagram (Afinity 17ST/20ST)

Illustrates electrical connections and components for Adfinity 17ST/20ST models.

Wiring Diagram (Afinity X20R)

Illustrates electrical connections and components for Adfinity X20R model.

Machine Use and Setup

Initial Battery Check and Setup

Guides on checking and setting up batteries for the first use of the machine.

Battery Installation and Type Setting

Details installing batteries, setting machine/charger types, and charging references.

Brush/Pad-holder Installation and Removal

Instructions for attaching and detaching brushes or pad-holders to the machine deck.

Brush Application Guide

Provides suggestions for matching brushes/pads to different floor types.

Squeegee Installation and Adjustment

How to install the squeegee and adjust its position for optimal drying.

Tank Filling Procedures

Procedure for filling the solution/washing water tank and detergent tank (X20R).

Machine Operation

Machine Start and Stop Procedures

Step-by-step guide on how to power on, operate, and safely shut down the machine.

Scrubbing and Drying Operation

Details the process of scrubbing and drying floors with the machine.

Detergent Concentration Adjustment (X20R)

How to adjust detergent concentration using controls on the Adfinity X20R.

EcoFlex™ System Features

Explains how to use the EcoFlex switch and manage its system features.

Extra Pressure Function (X20R)

How to use the brush/pad-holder extra pressure function on the Adfinity X20R.

Battery Discharge Warnings

Explains warning lights indicating battery status and advice for operation.

End of Use and Storage

Tank Emptying Procedures

Detailed steps for emptying the recovery water and solution/clean water tanks.

Post-Operation Tasks

Routine tasks to perform after completing operations, including cleaning and storage.

Machine Long Inactivity Storage

Procedures for storing the machine during extended periods of non-use.

First Period of Use Checks

Checks to perform after the initial 8 hours of operation.

Maintenance Procedures

Scheduled Maintenance Table

Outlines routine maintenance tasks and their recommended frequencies.

Battery Charging Procedure

Step-by-step guide on how to charge the machine's batteries.

Machine Working Hour Check

How to check the total operating hours recorded by the machine.

Squeegee Cleaning and Blade Maintenance

Procedure for cleaning squeegees and inspecting/replacing blades.

Brush/Pad and Tank System Cleaning

Steps for cleaning brushes, pads, tanks, and vacuum grid.

Filter Cleaning Procedures

Procedures for cleaning vacuum system and solution/clean water filters.

Fuse Check and Replacement

Guide to checking and replacing fuses in the machine's electrical system.

Detergent Tank and EcoFlex™ System Draining

Procedures for cleaning the detergent tank and draining the EcoFlex system.

Troubleshooting

Common Issues and Solutions

Lists common problems, their possible causes, and suggested remedies.

Scrapping and Disposal

Machine Disposal Guidelines

Guidelines for properly disposing of the machine and its components.
