P
24
85
-95M
M
25
P
P
Brake pedal forwarding distance :
85-95mm ( 3.35-3.74 inch)
To adjust the brake distance:
Do not loosen the brake cables
because of air leakage, which will
also affect the brake adjustment
and result in braking function.
1. Remove the cover of the dash board
2. Check the brake pedal by pressing
with two fingers with proper force
and measuring the forwarding
distance of the pedal until resistance
is felt.
CAUTION
Before adjusting the brake, tread
the brake pedal several times to
adjust the brakes.
Periodic Maintenance Chart
It is necessary to check periodically for
best performance and safe operation.
Do not fix brake cable too
tight as this
will make the brake adjust can't work
perfectly, and therefore lower down the
brake performance.
Before maintenance, make sure
that main switch is off and hand
brake on. Your local dealer or qualified
technician are responsible for it.
MaintenanceMaintenance
To Next Page
