Page: 10
ADVANTAGE ENGINEERING, INC.
525 East Stop 18 Road Greenwood, Indiana 46142
317-887-0729 Fax: 317-881-1277
Service Department Fax: 317-885-8683
Email: service@AdvantageEngineering.com
MK-10A shown
Air Cooled Condenser
Caster
Stainless Steel Frame
Electrical Cabinet
Instrument (LE shown)
Pressure Gauges
Protective Fan Shroud
Caster
Liquid Receiver
Compressor
Liquid Line Solenoid
Refrigerant Site Glass
Flow Switch
Fan Motor
Protective Fan Shroud
Air Discharge
Pressure Gauges (not visible)
Instrument (not visible)
Hot Gas Bypass Valve
Pump
Expansion Valve
Insulated Reservoir Tank
