Introduction
ADAM-3016 is a DIN rail-mounted strain gauge input signal conditioning module
with 1000 V
DC
3-way isolation between input, output and power. The switch con-
figurable input and output offers flexible, wide ranging capability for strain gauge.
ADAM-3016 is equipped with a power LED to monitor the line power and a DC-to-
DC converter status and 3 VR (ZERO, SPAN, EXCI) to calibrate input/output
range and excitation voltage.
The ADAM-3016 features three-way isolation. The power supply that drives the
module’s input circuitry and output circuitry is internally isolated, enabling
ADAM-3016 to offer true channel-to-channel isolation.
ADAM-3016’s input bandwidth is typically 2.4 kHz. The ADAM-3016 is powered
by a single +24V
DC
input. Power can be easily connected from the adjacent
modules, making the wiring simple and easy to maintain. The ADAM-3016 can
be mounted on a DIN rail and operate in environments with high humidity and
wide temperature variation.
