Configuration
Figure 1 shows the terminal wiring of ADAM-3016. Positive power terminals 9
and 7 are internally connected, as are negative terminals 12 and 10. Power can
be connected through the adjacent modules, making wiring much easier.
ADAM-3016 uses single +24 V
DC
. Table 1 and table 2 show the switch positions
to configure input and output range. The I/O configuration switches are located
inside the module. To reach the switches, you need to remove the DIN-rail bracket
by sliding it down.
