Utility Software
D-2 ADAM 4000 Series User's Manual
Normally you will use the Search command to scan the network. Highlight
the Search command on the menu bar and press <Enter> (or simply press
the “s” key). The “Search Installed Modules” window will then appear to
prompt you to enter the range it should scan. Input a value 0 and 256
decimal.
NOTICE: When changing configuration, calibration or alarm parameters,
you should always make sure that a window appears notifying you that
the target module has confirmed the changes.
An asterix sign “*” before the modules address indicates that the module
is in the INIT* state
Main menu
The main screen consists of a menu bar at the top side of the screen and a
status field which displays information about the connected modules.
When you first start the program, it will automatically scan for any attached
modules and display their data. The status field lists module characteristics,
module configuration parameters and in or output values.
Figure D-1
Main screen
