Safety Instructions (Cont.)
16. CAUTION: DANGER OF EXPLOSION IF THE BATTERY IS INCORRECTLY REPLACED. REPLACE ONLY WITH THE
SAME OR EQUIVALENT TYPE RECOMMENDED BY THE MANUFACTURER. DISCARD USED BATTERIES ACCORD-
ING TO THE MANUFACTURER’S INSTRUCTIONS.
17. The sound pressure level at the operator’s position according to IEC 704-1:1982 should be no more than 70 dB (A).
18. RESTRICTED ACCESS AREA: The equipment should only be installed in a Restricted Access Area.
19. DISCLAIMER: This set of instructions is given according to IEC 704-1. Advantech disclaims all responsibility for the ac-
curacy of any statements contained herein.
I/O Connectors
*Please refer to the user manual for eFuse (SW5) behavior.
CPU
DIMMA
PSON1
NVMe
USB 2.0
(top port only)
MPCIE1
MPCIE2/MSATA
DP2DP1
SPI_TPM1
& standoff
SATA
GPIO 1&2
COM
3&4
COM
5&6
SATA
Power
DIMMB
System Dimensions

Advantech MIC-770 V3 Specifications

General

Brand	Advantech
Model	MIC-770 V3
Category	Desktop
Language	English
