1.3
Dimensions
Dimensions: 583 x 386 x 69 mm (Unit: mm)
Figure 1.1 Dimens
ions of the
PDC
-W240
VESA M
ounting: 75 x 75 mm; 100x
100 mm
Please use M4x
12L (Maxium)screw.
Figure 1.2 VESA
Mounting o
f the P
DC
-W240
Warning!
Use suitable
mounting apparatu
s to avoid risk o
f injury.
11
13
Table of Contents
Instructions for the User
2
Safety Instructions
2
Explanation of Graphical Symbols
6
FCC Class B
7
List of Accessories
8
Additional Information and Assistance
8
General Information
10
Specifications
11
Cleaning and Disinfecting
13
System Setup
14
Installation Procedures
16
Connecting the Power Cord
16
Connecting the Ground Pin
16
Protecting Your Optical Drive
22
Disconnect the Power
22
Revision History
24
Install VESA Mounting
25
