MATERIALS INCLUDED IN THIS PACKAGE:
1) 10.2" TFT LCD Overhead Monitor With DVD Player - (1pc)
2) 12 Pin Power / Signal Harness (P/N 112-3483) - (1pc)
3) 2 Pin Power Wire Harness With Choke (P/N 112B3143) - (1pc)
4) AUX Pigtail (P/N 112B3227) - (1pc)
5) 12 Pin AV Adapter Cable (P/N 112-4094) - (1pc)
6) Hardware Package
Screws ISO M3 x 8mm Long - (5pcs)
#4 x 5/16" Self Tapping Screws - (1pc)
#4 x 7/16" Self Tapping Screws - (3pcs)
#8 x 3/8" Self Drilling Screws - (4pcs)
M5 Screws - (4pcs)
7) Remote Control (P/N 136-5055) - (1pc)
8) Universal Mounting Bracket (P/N 108-3921) - (1pc)
9) Pry Tool - (1pc)
10) USB Cover - (1pc)
11) Screw Cap - Shale - (2pcs)
- Pewter - (2pcs)
12) Trim Ring - Shale (P/N 102-4231) - (1pc)
- Pewter (P/N 102-4232) - (1pc)
13) Snap On Cover (Screen Back) - Shale (P/N 102-4233) - (1pc)
- Pewter (P/N 102-4234) - (1pc)
14) Snap On Cover (Shroud) - Shale (P/N 102-4596) - (1pc)
- Pewter (P/N 102-4597) - (1pc)
15) Wireless Headphones (P/N IR1CFF) - (2pcs)
16) Wireless Game Controller (P/N 136-4197) - (1pc)
Optional Accessories
17) SIRSWB Relay Box (P/N 112C3159) - (1pc)
18) FLO TV Harness Kit (P/N ADVFRK1) - (1pc)
3
TOOLS REQUIRED:
#2 Phillips Screwdriver
#1 Phillips Screwdriver
Utility or Razor Knife or Shears
Wire Strippers
Upholstery hook tool (for removal of panels as necessary)
Electrical Tape
Masking Tape
Multimeter (to verify 12 volt DC and continuity: Do not use a test light or logic probe)
Marker pen – to mark headliner
Scribe (to mark trim ring if used)
Misc. electrical connectors (to connect to vehicle power source). Requirements will vary from vehicle to vehicle)
DVD Movie (to verify system operation after installation)
