9
Left View
The following figure shows the left view of the notebook.
1. Power Connector
Connects the AC adapter so it can operate using the AC adapter
power or charge the battery.
2. HDMI Port
Provides an HDMI out port that allows you to connect external
monitors to your notebook.
3. Network Port
Allows you to connect to a network.
4. VGA Port
This port provides a 15-pin analogue VGA port to connect
external monitors to your notebook.
5. USB Port with charging function for external USB devices in
power off mode
USB 2.0 port used to connect external USB devices such as
keyboards and mice.
Connect the USB device you wish to charge and make sure the
notebook is in off mode. Press and hold the power button for 7
seconds. The blue USB charging indicator will come on indicating
that the charging function is enabled. Once enabled the USB
power will be enhanced from 500mA to 1.5A.
6. Cooling Vent
The cooling vent prevents the processor from overheating.
1 2 3 5 64
