11
ITEM NUMBER DESCRIPTION QTY
1 Screw M6x12 1
2 Clutch handle 1
3 O-ring Seal 1
4 Clutch Bush 1
5 Spring for clutch 1
6 Clutch shaft 1
7 Screw M5x25 6
8
Spring washer Φ5
6
9 Gear Box 1
10 Bearing 1
11 Sun Gear 1
12 3rd Planetary gear assembly 1
13 Clutch Gear 1
14 2nd Planetary gear assembly 1
15 Gear box lining 1
16 Inner gear 1
17 1st Planetary gear assembly 1
18 Screw M8x25 4
19
Spring washer Φ8
4
20 Gear box bracket 1
21 Bearing bush 1
22 Sealing washer 1
23 Transmission shaft 1
24 Drum assembly 1
25 Braking assembly 1
26 Front Tie bar 1
27 Back Tie bar 1
28 Motor assembly 1
29 Control box mount assembly 1
30 Fairlead 1
31 Hook 1
32 Power lead for wired control 1
33 Battery negative(-) cord 1
34 Wireless remote receiver 1
35 Hand held remote 1
36 Screw M5x20 2
37
Spring washer Φ5
2
38 Shaft 1
7. WINCH PARTS LIST
