8. WINCH SPECIFICATIONS
WINCH FEATURES
LINE PULL AND CABLE CAPACITY
LINE SPEED AND AMP DRAW (FIRST LAYER)
Rated Line Pull 12000lb (5443kg) single line
Motor 5.2KW/7HP 12V, Series Wound
Control Remote Switch, 12ft (3.7m) lead
Gear Train 3 Stage Planetary
Gear Reduction Ratio 218.4:1
Clutch Sliding Ring Gear
Braking Action Automatic In-The-Drum
Drum Dimensions
Φ2.6” x 8.8” (Φ64mm x 224mm)
Rope (Dia x L)
Φ10mm x 26mm
Fairlead Hawse Fairlead
Battery Recommended: 650CCA minimum for winching
Batery Leads 2 Gauge, 72”(1.83cm)
Overall Dimensions 525 x 160 x 186mm
Mounting Bolt Pattern 254mm x 114.3mm
Packing Size 57 x 19 x 5cm 1PC/CTN
Weight
N.W: 25kg
G.W: 26.5kg
Layers of Cable 1 2 3 4
Rated Line lb 12000 9210 8030 6894
Pull per Layer kg 5443 4170 3640 3125
Cumulative ft 17 41 71 91.8
Cable Capacity m 4.8 12 21 27.5
Line Pull
lb 0 4000 6000 8000 10000 12000
kg 0 1814 2721 3628 4536 5443
Line Speed
ft/min 30.2 13.8 11.5 10 7.5 5.7
m/min 9.2 4.2 3.5 3.05 2.3 1.75
Motor Amps 65 165 215 272 345 420
