EN
7 Technical data
Parameter
Value
StecaGrid 8000 3ph StecaGrid 10000 3ph
DC input side (PV generator connection)
Number of DC inputs 3 5
Maximum start voltage 845 V
Maximum input voltage (V
dcmax
) 845 V
Minimum input voltage (V
dcmin
) 350 V
Rated input voltage (V
dc,r
) 600 V
Minimum input voltage for rated output 350 V
MPP voltage (V
mppmin
… V
mppmax
) 350 V … 700 V
Maximum input current (I
dcmax
) 27 A 32 A
Rated input current 14 A 16.7 A
Maximum input power 9,250 W 10,800 W
Rated input power 8,400 W 10,000 W
Recommended maximum PV output 10,500 Wp 12,500 Wp
Derating / restriction automatic when:
• input power is higher
• the device is not cooled sufficiently
• input currents > 27 A
automatic when:
• input power is higher
• the device is not cooled sufficiently
• input currents > 32 A
Higher currents are restricted by the inverter and therefore will not damage it.
AC output side (mains grid connection)
Output voltage (V
acmin
… V
acmax
) 320 V … 480 V [depending on the regional settings]
Rated output voltage (V
ac,r
) 400 V
Maximum output current (I
acmax
) 15 A
Rated output current 11.6 A 13.7 A
Maximum output power 8,800 W 10,300 W
10,000 W (Belgium only; see table of
countries)
Rated output (P
ac,r
) 8,000 W 9,500 W
Rated frequency (f
r
) 50 Hz
Grid frequency (f
min
… f
max
) 47.5 Hz ... 52 Hz [depending on the regional settings]
Power losses in nighttime operation < 1.6 W
Feeding phases three-phase
Distortion factor < 4% (max. output)
Characterisation of the operating behaviour
Maximum efficiency 96.3%
European efficiency (η
EU
) 95.2% 95.4%
MPP efficiency > 99%
Operating efficiency (at 5 %, 10 %, 20 %,
25 %, 30 %, 50 %, 75 %, 100 % of rated
power) at minimum MPP voltage
84.4 %, 91.8 %, 94.5 %, 95 %, 95.1 %,
95.6 %, 94.7 %, 94.3 %
88.3 %, 93.2 %, 95 %, 95.2 %, 95.3 %,
95.6 %, 94.8 %, 94.3 %
Operating efficiency (at 5 %, 10 %, 20 %,
25 %, 30 %, 50 %, 75 %, 100 % of rated
power) at maximum MPP voltage
74.1 %, 92.7 %, 94.8 %, 95.5 %, 95.7 %,
96.2 %, 95.8 %, 95.3 %
77.2 %, 94.1 %, 95.3 %, 95.7 %, 95.9 %,
96.2 %, 95.9 %, 95.3 %
Efficiency reduction in the case of devia-
tion from the DC rated voltage
–0.0025% / V
Power derating at full power from +50 °C (T
amb
)
Switch-on power 20 W
Switch-off power 40 W
Standby power 9 W
49
