AEE sd20 - Product Structure

-4-
1.
2.
3.
4.
5.
6.
7.
8.
11.
12.
13.
14.
15.
16.
10.
20.
21.
19.
TFT display screen
MENU key
Up key
Left key
Down key
Recall key
OK key
Push button of TFT
display screen clip
Lanyard hole
Product Structure (outline drawing)
Buzzer
SD card slot
Right key
USB output interface
Record
Green indicator of
video/voice recording
Power switch
Microphone
Red indicator of working/charging
17.
9.
18.
LCD segment screen
Shutter
VOX switch
1
2
3
4
11
98
14
16
192021
5
12
13
15 18
7
17
10
6
