AEG 34602G - Engineers Technical Data; Instructions for the Installer

13
Overall dimensions
Width: 580 mm.
Depth: 500 mm.
Cut out dimensions
Width: 550 mm.
Depth: 470 mm.
Supply Connections
Gas: RC 1/2 inch (1/2 inch male) Rear right
hand corner
Electric:230 V 50 Hz supply, 3 core flexible cable
with non rewireable plug fitted with a 3 amp cartridge
fuse.
Instructions for the Installer
Engineers technical data
BURNER RAPID SEMI-RAPID AUXILIARY
(large) (medium) (small)
POSITION MAX MIN MAX MIN MAX MIN
NOMINAL THERMAL
POWER kW 3 .0 0.65 2.0 0.45 1.0 0.33
NOMINAL FLOW
RATE m
3
/h 0.286 0.057 0.190 0.038 0.095 0.028
NOZZLE REFERENCE 119 Adjust. 96 Adjust. 70 Adjust.
1/100 mm
NOMINAL THERMAL
POWER kW 2 .8 0.65 2.0 0.45 1.0 0.33
NOMINAL FLOW
RATE g/h 202 43.5 144 29 72 21,5
NOZZLE REFERENCE 86 40 71 32 50 28
1/100 mm
NATURAL GAS
20 mbar
VALUE =
37.78 MJ/m
3
Ws - 50.7 MJ/ m
3
TYPE OF GAS
LPG GAS
28-30/37 mbar
VALUE =
49.92 MJ/Kg
Heat Input
Rear Left Burner 2.0 kW (6824 BTU/HR)
(semi rapid)
Front Left Burner 3.0 kW Natural Gas
(rapid) (10236 BTU/HR)
2.8 kW L.P.G.
(9554 BTU/HR)
Rear Right Burner 2.0 kW (6824 BTU/HR)
(semi rapid)
Front Right Burner 1.0 kW (3412 BTU/HR)
(auxiliary)
Appliance class 3
Appliance category II2H3+
Gas supply Natural gas G 20 / 20 mbar
