AEG 8360 D - Changing the Light Bulb

10
Warning
• Failure to observe the instructions on cleaning the unit and
changing the filters will cause a fire hazard. You are therefore
strongly recommended to follow these instructions.
• The manufacturer declines all responsibility for any damage to the
motor or any fire damage linked to inappropriate maintenance or
failure to observe the above safety recommendations.
Changing the light bulb
• Disconnect the cooker hood from the main supply.
8160 D - 8190 D
• Remove the lamp cover. Fig. 5.
• Replace the old bulb with a new
one of the same type.
• Remount the lamp cover.
8260 D - 8290 D - 8360 D - 8390 D -
8361 D - 8391 D
• Press (1) the lamp cover (2) and
open it. Fig. 6.
• Replace the old bulb with a new
one of the same type (3).
• Close the lamp cover.
• If the light does not come on,
make sure the bulb has been
inserted correctly before
contacting your local Service
Force Centre.
3
1
2
Fig. 6
1
2
Fig. 5
