AEG 88840 - Technical Data; Hints for Test Institutes

Technical data
This appliance conforms with the following EU Directives:
– 2006/95/EC dated 12.12.2006 Low Voltage Directive
– 89/336/EEC dated 03.05.1989 EMC Directive inclusive of Amending Directive 92/31/EEC
– 93/68/EEC dated 22.07.1993 CE Marking Directive
Height x width x depth 85 x 60 x 58 cm
Drum volume 108 l
Depth with loading door open 109 cm
Height can be adjusted by 1.5 cm
Weight when empty approx. 48 kg
Loading volume (depends on programme)
1)
max. 7 kg
Voltage 230-240 V
Required fuse 13 A
Total power 2350 W
Energy efficiency class
B
Energy consumption (7 kg of cotton, pre-
drained at 1000 rpm)
2)
3.92 kWh
Average annual energy consumption 284.1 kWh
Use Domestic
Permissible ambient temperature + 5°C to + 35°C
Consumption values
The consumption values have been established under standard conditions. They may deviate when
the machine is operated in domestic circumstances.
Programme
Energy consumption in kWh / average dry-
ing time in min.
COTTON CUPBOARD DRY
2) 3)
3.92 / 125 (7 kg load pre-drained at 1000 rpm)
3,75 (7 kg load pre- drained at 1200 rpm)
3,60 (7 kg load pre- drained at 1400 rpm)
3,20 (7 kg load pre- drained at 1800 rpm)
COTTON IRON DRY
2)
3.34 / 107 (7 kg load pre-drained at 1000 rpm)
SYNTHETICS CUPBOARD DRY
2)
1.33 / 48 (3 kg load pre-drained at 1200 rpm)
1) Different loading volume data may be needed in some countries as a result of different measuring methods.
2) in accordance with EN 61121
Hints for test institutes
Parameters possible to be checked by the Test Institutes:
• Energy consumption (corrected with final humidity) during the cupboard dry cotton
cycle with nominal load.
