Connect an inflator/air compressor to the valve and
pressurise the tank to a maximum of 125 psi. Allow the
tool to recharge for approximately 30 seconds.
Type of air chuck required: Compatible with Schrader
Valve with 0.305”-32TPI thread
NOTE: It is normal to hear a hissing sound while the
tank is being refilled. Do not overfill. Always check
the pressure before use. If overfilling occurs, a safety
overflow valve will open to allow the excessive pressure
to escape. Once the pressure has decreased, the valve
will close automatically.
Single head air chuck for use with a
Schrader valve
A18HPI BHPV18
WARNING!
Never pressurise the tank to more than 125 psi. Failure
to heed this warning can result in serious personal
injury.
Dual head air chuck for use with a
Schrader valve
