Page #3 background imageLoading...
Page #3 background image
2
ERROR CODE TABLE
Code Description Solution
Err01 Out of measuring range Measure in a proper range
Err02
Choose a better surface
Err03 Out of display range (max value:
999.99) e.g. result of area or volume
is out of display range
Check and verify values and steps
are correct
Err04 Pythagorean calculation error Check and verify values and steps
are correct
Err05 Battery is low Install new batteries
Err06 Out of working temperature Measure in an environment with the
Err07 Ambient light is too strong Measure in a darker place (shadow
target)
SPECIFIED CONDITIONS OF USE
The laser distance measurer can be used for measuring distances and tilts.
Do not use this product in any other way as stated for normal use.
TECHNICAL DATA
Dust and Water resistance IP54
Receiving Lens 14 mm
Focus 35 mm
Maximum Measuring Range 100 meters
Minimum Measuring Range 0.05 meters
Absolute Accuracy @ < 10m ± 1.5 mm (Max)
Repeatability Accuracy @ < 10m ± 1.5 mm (Max T\SLFDOı
Repeatability Accuracy @ > 10m Increase ± 0.25 mm / meter (Max T\SLFDOı
Measurement Time 0.5 s
Display Type LCD ( 31.8 mm x 32 mm )
Power Type AAA 2x (Alkaline Battery)
Battery Life 10000 (Single Measure)
Laser Output Power 0.6 mW ~ 0.95 mW (Class 2, 650nm )
Laser Spot Size 25 mm x 30 mm @ 15 m(Max)
Laser Radiation Vertical Angle ±1 degree
Laser Radiation Horizontal Angle ±1.5 degree
Device auto off time 180 seconds
Laser auto off time 30 seconds
Operating Temperature Range -10°C to +50°C
Storage Temperature Range -25°C to +70°C
Weight without Battery 99 g
SPECIFIED CONDITIONS OF USE
The laser distance measurer can be used for measuring distances and tilts.
Do not use this product in any other way as stated for normal use.
