11
English
n Turn the fuel valve to the ON position.
n Turn the key to “START” position and release.
n Allow the engine to run for 30 seconds, then move the
choke lever in to the RUN position.
See Figures 6- 7.
n Remove any load from the generator.
n Switch the AC circuit breakers to the OFF position.
n Disconnect DC battery charging cables.
n Turn the fuel valve to the OFF position.
n Put the engine switch in the OFF ( O ) position.
n Turn the key to "OFF" position (Electric start only).
n Put the engine switch in the OFF ( O ) position.
When servicing, use only identical Ryobi
replacement parts. Use of any other parts may
create a hazard or cause product damage.
Only the parts shown on the parts list are intended to be repaired
or replaced by the customer. All other parts should be replaced
at an authorised service centre.
Keep the generator in a clean and dry environment where it is
not exposed to dust, dirt, moisture, or corrosive vapors. Do not
allow the cooling air slots in the generator to become clogged
with foreign material such as leaves, snow, etc.
Do not use a garden hose to clean the generator. Water entering
the fuel system or other internal parts of the unit can cause
problems that will decrease the life of the generator.
n Use a soft bristle brush and/or vacuum cleaner to loosen
and remove dirt and debris.
n Clean air vents with low pressure air that does not
exceed 25 psi.
n Wipe the exterior surfaces of the generator with a damp
cloth.
See Figure 9.
For proper performance and long life, keep air lters clean.
n
Lift the latches located at the top and bottom of the
air
filter cover. Remove the cover and set aside.
n Remove the filter elements.
n If the filter elements are dirty, clean with warm, soapy
water. Rinse and let dry.
n Apply a light coat of engine oil to the elements, then
squeeze it out.
n Replace the elements in the air filter unit.
n Replace the air filter cover and close latches to secure.
Do not run the generator without the air filter.
Rapid engine wear will result.
See Figure 10.
n Remove the oil cap/dipstick.
n Place a container underneath the oil drainage bolt to
collect used oil as it drains.
n Unscrew the oil drainage bolt and remove.
n Allow oil to drain completely.
n Reinstall the oil drainage bolt and tighten securely.
n Refill with oil following the instructions in the
section.
n Reinstall the oil cap/dipstick.
Used oil should be disposed of at an approved
disposal site. See your local oil retailer for more information.
See Figure 11.
The sediment cup prevents dirt and water that may have gotten
into the fuel tank from entering the carburetor. If the engine
has not been run for a long time, the sediment cup should be
cleaned before use.
n Turn the fuel valve to the OFF position.
n Remove the sediment cup using a 10 mm wrench (not
provided).
n Remove the O-ring and filter.
n Clean each of the parts in carburetor cleaner or any
comparable cleaning product.
n Reinstall the filter, O-ring, and sediment cup. Tighten with
wrench to secure.
n Return the fuel valve to ON position and check for leaks.
See Figure 12.
The spark plug must be properly gapped and free of deposits
in order to ensure proper engine operation. To check:
n Remove the spark plug cap.
n Clean any dirt from around base of spark plug.
n Remove spark plug using wrench provided.
n Inspect spark plug for damage, and clean with a wire
brush before reinstalling. If insulator is cracked or
chipped, spark plug should be replaced.
If replacing, use the following recommended
spark plugs or equivalent: Champion RN11YC or NGK
BPR6ES.
