4. With a key, loosen the lower pin.
On the opposite side:
1. Tighten the lower pin.
2. Install the spacer.
3. Install the door.
4. Tighten the upper pin.
Ventilation requirements
The airflow behind the appliance must be suffi-
cient.
Installing the appliance
CAUTION!
Make sure that the mains cable can move freely.
Do the following steps:
1. If necessary cut the adhesive sealing
strip and then apply it to the appliance
as shown in figure.
5 cm
min.
200 cm
2
min.
200 cm
2
x
x
Installation 15
