AEG B16N18 - Page 4

4
4
Fig. 5 Fig. 8 (for B16N18 only)
Fig. 9 (for B16N18 only)
A - Rear loading magazine
B - Nails
C - Nail tips
Fig. 6 Fig. 7
A - Power adjustment lever
B - Increase pressure
C - Decrease pressure
A - Depth of drive adjustment
B - To increase depth
C - To decrease depth
A - Trigger switch
B - Workpiece contact
A - Mode selector switch
B - Full sequential actuation mode
C - Contact actuation mode
