4. PRODUCT DESCRIPTION
4.1 General overview
1
2
3
3
4
5
5
6
5
4
3
2
1
8
3
2
1
4
7
1
Control panel and hob
2
Air vents for the cooling fan
3
Heating element
4
Lamp
5
Shelf support, removable
6
Fan
7
Cavity embossment
8
Shelf positions
4.2 Hob overview
140/210 mm
180 mm
180 mm
145 mm
2
1 1
11
1
Cooking zone
2
Residual Heat Indicator
4.3 Cooker control panel
67
1 2 543 1
1
Knobs for the hob
2
Knob for the top oven functions
3
Display
4
Knob for the main oven functions
5
Knob for the main oven temperature
6
Temperature indicator / symbol for the
main oven
7
Temperature indicator / symbol for the top
oven
4.4 Accessories
• Wire shelf
For cookware, cake tins, roasts.
• Grill- / Roasting pan
To bake and roast or as pan to collect fat.
• Trivet
For roasting and grilling.
Use the trivet only with the Grill- /
roasting pan.
