13
Installation
Power Supply/ Battery
For maximum battery capacity, charge the battery for the first time at least 20 hours
without connecting the telephone line.
1. Insert the power plug in the power jack (17) in the back 17
of the base set. 18
2. Plug the adaptor into a power outlet. (230V~).
3. Open the battery compartment (13). (Fig. a).
4. Install the battery into the compartment. (Fig. b).
Be sure of the correct polarisation!
5. Close the battery compartment. (Fig. c).
6. Install the handset on the base set. The line/ charge indicator
(20) will light up.
Telefone Line
1. Plug the Telefone line cord into the Telefone line jack (18) in the back of the base
set.
2. Plug the other end of the telephone line cord (TAE) in the telephone wall outlet.
( F-code).
The telephone is now operational.
Beltclip
1. Slide the belt clip over the back of the handset up to the notches.
2. To remove the belt clip lift one end from a notch.
Notches belt clip
