INSTALLATION
9
RECIRCULATION VERSION AIREOUTLET
To install the hood in recycling version, the
optional charcoal filter kit must be purchased.
• Removethechimneyanglebracket.
• Screwthefiltercoverontotheairoutlet,
using four screws 12c (2.9 x 12.5).
• Fixtheairoutletgrid 8 on the recircula-
tion air outlet using the 2 screws 12d (2,9
x 9,5) provided.
ELECTRICAL CONNECTION
• Connectthehoodtothemainssupply.
• OpentheupperpanelbypressingtheA-key
(See Part “USE” ) for at least 2 seconds.
• Removethemetalfilters(SeePart“MAINTE-
NANCE”) and make sure that the connector
piece of the supply cable is correctly inside the
hood socket.
FLUE ASSEMBLY
Upper exhaust Chimney
• Slightlywidenthetwosidesoftheupper
chimney and hook them behind the brack-
ets 7.2.1, making sure that they are well
seated.
• Securethesidestothebracketsusingthe4
screws 12c (2,9 x 9,5) supplied.
Lower exhaust Chimney
• Slightlywidenthetwosidesofthechimney
and hook them between the upper chimney
and the wall, making sure that they are
well seated.
• Fixthelowerpartlaterallytothehood
body using the 2 screws 12c (2,9 x 9,5)
supplied.










