Recirculation mode
• The air is filtered through a charcoal filter and returned to the
kitchen.
• You will need an original charcoal filter for the recirculation mode.
(See Special Accessories).
• Fix the deflector using 2 screws Ø 2,9x13 mm. Fig. 2.
• Optionally, the position of the chimney elements can be changed.
When using the hood in the recirculation mode the chimney must be
fixed at the top, with the air outlet grill at the side.
Fig. 2
