AEG HD 8760 - Technical Specifications; Mounting Accessories Included

13
Technical Specifications
HD 8795 HD 8760
Dimensions (in cm):
Height x Width x Depth 80 x 89,8 x 33,5 80 x 89,8 x 33,5
Maximum absorbed power: 235 W 235 W
Motor absorption: 175 W 175 W
Lighting*: 3 x 20W
(30° Ø35 12V GU4) (30° Ø35 12V GU4)
Length of the cable: 150cm 150 cm
Electrical connection: 240 V 240 V
Fuse 5A
* Attention! To guarantee the same quality of illumination we advise using the
same type of light: Halogen Lamp PHILIPS STANDARD LINE Code 425409, 20W 30°
Ø35 12V GU4
Mounting accessories included
1 allen spanner for torx screw
1 support bracket
1 deflector
2 Screw caps
1 Rubber strips (to be divided in 3 pieces)
1 template
2 spacers
4 wood-screws 5 x 45 mm
4 wall plugs Ø 8 mm
2 metal screws 3,5 x 9,5
2 metal screws 3,5 x 32
2 metal screws 5 x 18
1 reduction flange Ø 150-125 mm
2 flanges Ø 150 mm
Only HD 8795: 2 Stainless Steel side panels
