If the appliance is installed
above a drawer, the hob
ventilation can warm up the
items stored in the drawer
during the cooking process.
10. TECHNICAL DATA
10.1 Rating plate
Model IKE95471FB PNC 949 597 379 00
Typ 62 E5A 05 AA 220 - 240 V / 400 V 2N 50 - 60 Hz
Induction 7.35 kW Made in Germany
Ser.Nr. ................. 7.35 kW
AEG
10.2 Cooking zones specification
Cooking zone Nominal power
(maximum heat
setting) [W]
PowerBoost
[W]
PowerBoost
maximum dura-
tion [min]
Cookware diam-
eter [mm]
Middle front 1800
3500
2800
3700
10
10
145 - 245
245 - 280
Right front 1400 2500 4 125 - 145
Right rear 2300 3200 10 180 - 210
Flexible induc-
tion cooking
area
2300 3200 10 minimum 100
The power of the cooking zones can be
different in some small range from the
data in the table. It changes with the
material and dimensions of the
cookware.
For optimal cooking results use
cookware no larger than the diameter in
the table.
ENGLISH 23
