AEG L7FC8432BI User Manual

The inlet hose
1. Remove the inlet hose from inside the
drum.
2. To connect the water inlet hose towards
the proper direction and with the proper
inclination, check the position of the water
tap before connecting it to the back of the
appliance.
Make sure the hose is nor
kinked, squashed but neither
tensed.
20
O
20
O
45
O
45
O
3. Connect the hose to the back of the
appliance. Do not turn the inlet hose
downwards, but turn it left or right depending
on the position of your water tap.
4. Loosen the ring nut to fix it in the correct
position.
5. Connect the water inlet hose to the cold
water tap with 3/4 thread.
WARNING!
Make sure that there are no
leaks from the couplings.
Use the hose supplied with appliance.
Do not use an extension hose if the inlet hose is too short. Contact the
Authorised Service Centre for an inlet hose replacement.
Water drainage
The drain hose can be connected:
www.aeg.com10

AEG L7FC8432BI Specifications

General

Door color	Stainless steel
Door hinge	Left
Cord length	1.5 m
Drum volume	52 L
Control type	Rotary
Loading type	Front-load
Product color	White
Built-in display	Yes
Custom panel-ready	No
Outlet hose length	0.145 m
Appliance placement	Freestanding
Dispenser tray type	3-way
Drum capacity	8 kg
Cycle time (max)	295 min
Residual moisture	52 %
Spin-drying class	B
Maximum spin speed	1400 RPM
Noise level (spin)	68 dB
Noise level (wash)	46 dB
Number of washing programs	-
Cycle time (quick washing program)	20 min
Current	13 A
Connected load	2000 W
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Energy efficiency scale	A to G
Power consumption (off)	0.3 W
Water consumption per cycle	47 L
Energy consumption washing per cycle	0.82 kWh

Weight and Dimensions

Depth	554 mm
Width	596 mm
Height	819 mm
