AEG L7FC8432BI User Manual

Ø 40 mm
To a stand pipe with vent-hole
Directly into a drain pipe at a height of not
less than 60 cm (23.6”) and not more than 100
cm (39.3”).
The end of the drain hose must always be
ventilated , i.e. the inner diameter of the drain
pipe (min. 40 mm - min. 1.6”) must be larger
than the external diameter of the drain hose.
max.
600 mm
To a sink spigot
Put the drain hose in the spigot and tighten it
with the supplied cable tie L.
Make sure that the drain hose makes a loop
to prevent particles going into the appliance
from the sink.
L
To a wall-pipe
Directly to a built-in drain pipe in the room
wall and tighten it with the supplied cable tie
L.
You can extend the drain hose to maximum 400 cm. Contact the service
centre for the other drain hose and the extension.
3.7 Building in
600 mm
min.
820 mm
min.
560 mm
16-22 mm
min.
This appliance has been designed to be built
into the kitchen furniture. The recess should
have the dimensions shown in this picture.
For recess with a height
different than 820 mm, it is
possible to buy the
appropriate kit on the website.
ENGLISH 11

AEG L7FC8432BI Specifications

General

Door color	Stainless steel
Door hinge	Left
Cord length	1.5 m
Drum volume	52 L
Control type	Rotary
Loading type	Front-load
Product color	White
Built-in display	Yes
Custom panel-ready	No
Outlet hose length	0.145 m
Appliance placement	Freestanding
Dispenser tray type	3-way
Drum capacity	8 kg
Cycle time (max)	295 min
Residual moisture	52 %
Spin-drying class	B
Maximum spin speed	1400 RPM
Noise level (spin)	68 dB
Noise level (wash)	46 dB
Number of washing programs	-
Cycle time (quick washing program)	20 min
Current	13 A
Connected load	2000 W
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Energy efficiency scale	A to G
Power consumption (off)	0.3 W
Water consumption per cycle	47 L
Energy consumption washing per cycle	0.82 kWh

Weight and Dimensions

Depth	554 mm
Width	596 mm
Height	819 mm
