AEG LFR6114O2B User Manual

14.8 Cleaning the detergent
dispenser
To prevent possible deposits of dried
detergent or clotted fabric softener
and/or formation of mould in the
detergent dispenser drawer, once in a
while carry out the following cleaning
procedure:
1. Open the drawer. Press the catch
downwards as indicated in the
picture and pull it out.
1
2
2. Remove the top part of the additive
compartment to aid cleaning and
flush it out under running warm
water, to remove any traces of
accumulated detergent. After
cleaning, put the top part back into
position.
3. Make sure that all detergent residue
is removed from the upper and lower
part of the recess. Use a small brush
to clean the recess.
4. Insert the detergent drawer into the
guide rails and close it. Run the
rinsing programme without any
clothes in the drum.
14.9 Cleaning the drain pump
WARNING!
Disconnect the mains plug
from the mains socket.
Regularly check the drain
pump filter and make sure
that it is clean.
Clean the drain pump if:
• The appliance does not drain the
water.
• The drum does not turn.
• The appliance makes an unusual
noise because of the blockage of the
drain pump.
• The display shows the alarm code
.
ENGLISH 31

AEG LFR6114O2B Specifications

General

Door type	Tempered glass
Door hinge	Left
Cord length	1.8 m
Drum volume	68.6 L
Control type	Rotary
Display type	LED
Door opening	Side opening
Loading type	Front-load
Product color	White
Built-in display	Yes
Appliance placement	Freestanding
Connected load	2200 W
AC input voltage	230 V
AC input frequency	50 Hz
Energy efficiency scale	A to G
Water consumption per cycle	52 L
Energy consumption washing per cycle	0.512 kWh
Drum capacity	10 kg
Cycle time (max)	230 min
Spin-drying class	B
Maximum spin speed	1400 RPM
Noise level (spin)	76 dB
Noise level (wash)	- dB
Number of washing programs	-
Automatic dosing system	No

Weight and Dimensions

Depth	636 mm
Width	597 mm
Height	847 mm
