AEG LFR6114O2B User Manual

WARNING!
• Do not remove the filter
while the appliance
operates.
• Do not clean the pump if
the water in the appliance
is hot. Wait until the water
cools down
Proceed as follows to clean the pump:
1. Open the pump cover.
1
2
2. Place a suitable bowl below the drain
pump access to collect the water that
flows out.
3. Open the chute downwards. Always
keep a rag nearby to dry up any
water spillages when removing the
filter.
4. Turn the filter 180 degrees in anti-
clockwise direction to open it, without
removing. Let the water flow out.
180˚
5. When the bowl is full of water, turn
the filter back and empty the
container.
6. Repeat the steps 4 and 5 until the
water stops to flow out.
7. Turn the filter anti-clockwise to
remove it.
2
1
8. If it is necessary, remove fluff and
objects from the filter recess.
9. Make sure that the impeller of the
pump can rotate. If it does not rotate,
contact the Authorised Service
Centre.
10. Clean the filter under the water tap.
www.aeg.com32

AEG LFR6114O2B Specifications

General

Door type	Tempered glass
Door hinge	Left
Cord length	1.8 m
Drum volume	68.6 L
Control type	Rotary
Display type	LED
Door opening	Side opening
Loading type	Front-load
Product color	White
Built-in display	Yes
Appliance placement	Freestanding
Connected load	2200 W
AC input voltage	230 V
AC input frequency	50 Hz
Energy efficiency scale	A to G
Water consumption per cycle	52 L
Energy consumption washing per cycle	0.512 kWh
Drum capacity	10 kg
Cycle time (max)	230 min
Spin-drying class	B
Maximum spin speed	1400 RPM
Noise level (spin)	76 dB
Noise level (wash)	- dB
Number of washing programs	-
Automatic dosing system	No

Weight and Dimensions

Depth	636 mm
Width	597 mm
Height	847 mm
