51
ENGLISH
9. INSTALLATION
The microwave can be fitted in position
A or B:
A
B
Conventional
oven
Position
Niche size
W D H
A 562 x 550 x 380
562 x 550 x 450
B 562 x 500 x 380
562 x 500 x 450
9.1 Installing the appliance
1. Remove all packaging and check
carefully for any signs of damage.
2. Fit the fixing hooks to the kitchen
cupboard using the instruction sheet
and template supplied.
3. Fit the appliance into the kitchen
cupboard slowly, and without force.
The appliance should be lifted onto the
fixing hooks and then lowered into
place. In the case of interference
during fitting, this hook is reversible.
The front frame of the oven should
seal against the front opening of the
cupboard.
4. Ensure the appliance is stable and not
leaning. Ensure that a 4 mm gap is
kept between the cupboard door above
and the top of the frame (see diagram).
