5.6 Removing ExtraZone
There is a pull-out drawer above the
GreenZone drawer.
It is recommended to empty
the drawer before removing
it from the fridge.
To remove the drawer:
1. Pull out the drawer from the fridge
extending the rails fully.
2. Push the rails cap and lift up the front
of the drawer.
3. Pull the drawer out while lifting it up
and detach it from the rails.
2
1
4. Push the rails inside the cabinet to
avoid damage to the appliance when
closing the door.
To reassemble:
1. Pull out the rails completely.
2. Place the rear part of the drawer on
the rails.
1
2
3. Keep the front of the drawer lifted up
while pushing the drawer in.
4. Press the front part of the drawer
downwards.
Pull out the drawer again
and check if it is placed
correctly on both rear and
front hooks.
To remove the glass shelf:
