1. Open the door.
2. Remove the transport support from the
door sides.
3. Remove the transport support from the
lower hinge (some models).
4. Remove the transport support from un-
derneath the water unit.
5. Cut the pump securing tie and remove
it.
Some models are fitted with a silencing pad
under the cabinet. Do not remove this pad.
Rear spacers
Install the spacers provided within the accessory bag as shown in the figure.
Install two spacers on the back side of the panel
and two spacers with adhesive on the lower part.
Connecting the water hose.
Water supply should be provided with a tap and 3/4" male connector within 1,5 m from the
appliance.
3
2
4
5
22 Installation
