4. Adjust the appliance in the niche.
Make sure that the distance between
the appliance and the cupboard front-
edge is 44 mm.
The lower hinge cover (in the accessories
bag) makes sure that the distance be-
tween the appliance and the kitchen
furniture is correct.
Make sure that the clearance between
the appliance and the cupboard is 4
mm.
Open the door. Put the lower hinge cov-
er in position.
5. Attach the appliance to the niche with 4
screws.
6. Remove the correct part from the hinge
cover (E). Make sure to remove the part
DX, in the case of right hinge, SX in op-
posite case.
44mm
4mm
I
I
22 Installation
